E Ride 32
E Ride 32
Specifications
Cylindrical Brush Head: (2) 1 HP, 900 RPM
Disc Brush Head: 2 HP dual right angle with gearbox 300 RPM
Drive Motor: 1.2 HP traction drive with e-mag brake
Front Wheels: 3 1/2″ x 12″ solid w/cross hatch (9cm X 30cm)
Front Wheels: 3 1/2″ x 12″ solid w/cross hatch (9cm X 30cm)
Height: 54″ (137 cm)
Length: 63″ (160 cm)
Rear Wheels: 4″ 14″ soft ride (10cm x 36cm) cross hatch
Disc Brush Head: 2 HP dual right angle with gearbox 300 RPM
Drive Motor: 1.2 HP traction drive with e-mag brake
Front Wheels: 3 1/2″ x 12″ solid w/cross hatch (9cm X 30cm)
Front Wheels: 3 1/2″ x 12″ solid w/cross hatch (9cm X 30cm)
Height: 54″ (137 cm)
Length: 63″ (160 cm)
Rear Wheels: 4″ 14″ soft ride (10cm x 36cm) cross hatch
Recovery Capacity: 38 Gal (144 liters)
Solution Capacity: 32 Gal (121 liters)
Squeegee Width: 34 1/2″
Vacuum Power: 1 HP, 3-stage tangential bypass
Weight: 1,242 lbs (563 kg)
Weight without drive/batteries: 822 lbs (373 kg)
Width with Squeegee: 30″ (76 cm)
Solution Capacity: 32 Gal (121 liters)
Squeegee Width: 34 1/2″
Vacuum Power: 1 HP, 3-stage tangential bypass
Weight: 1,242 lbs (563 kg)
Weight without drive/batteries: 822 lbs (373 kg)
Width with Squeegee: 30″ (76 cm)
E Ride 32
Key Features:
- Single front wheel drive provides optimum traction and allows it to turn 360 degrees on its’ own axis for on-the-spot floor scrubbing maneuverability
- Cushioned safety seat is ergonomically designed for operator comfort
- Two-position column in operator compartment provides optimum operator comfort while climbing onto the machine
- Conveniently located control panel with a directional switch to regulate the forward and reverse direction of the scrubber
- Easy-to-read control panel with five position switch to control various functions
- The rear squeegee assembly utilizes a breakaway design in case of impact and automatically lowers when the machine is moving forward and automatically raises in reverse
- Cushioned safety seat will not allow the scrubber to move unless the operator is seated
- Polyethylene battery tray helps prevent acid spills and protects machine
- A 180 degree view from the operator seat makes operation a breeze with no blind spots
- Three electronic brakes for safety: E-mag, Dynamic, Plugging
- Self tracking squeegee leaves floor virtually dry in one pass and ready for traffic
- Click here to learn about SPORT technology.
